As a renowned and trusted producer of Portable EOD Jamming System with RC Rover, our factory excels in delivering exceptional products, backed by a steadfast commitment to punctual delivery and unparalleled after-sales support. We are deeply proud of our manufacturing prowess, stringent quality assurance protocols, and our capability to tailor professional products that precisely align with your unique requirements.
Highlight: mobile phone signal jammer high power, high power cell phone jammer
Product Name: | Portable EOD Jamming System with RC Rover | Power Supply: | AC 220V |
One Band Output Power: | 10-100Watt | Power Consumption: | 1000W |
Dimensions: | 800×500×310 Mm | Frequency Band: | 1-8 Channel |
Weight: | 53.6kg | Antennas: | 8pcs Omni Antennas |
Mobile Phone Convoy Bomb Jammers High Integration 1000W Power PHS / 3G / 4G AC 220V
Portable EOD Jamming System with RC Rover for CDMA / GSM / DCS / PHS / 3G / 4G / WIFI
● Using UHF broadband interference technology.
● High effective power (channel power) and large interference radius.
● Imported device, slow start circuit design can avoid the mechanical switch fire phenomenon, high integration, stable work.
● Perfect self-protection function. When the device is warned of overheating fault, the shielding device will automatically shut down the failed module to avoid the damage of the shielding device.
Channel | Working Frequency | Output Power(±3dBm) |
CH1 | 20-100 MHz | 44.77dBm |
CH2 | 100-300MHz | 44.77dBm |
CH3 | 300-500MHz | 47dBm |
CH4 | 800-1000MHz | 47dBm |
CH5 | 1520- 1670 MHz | 48.75dBm |
CH6 | 1800-2000 MHz | 48.75dBm |
CH7 | 2000-2200 MHz | 48.75dBm |
CH8 | 2400-2690 MHz | 48.75dBm |
Power: AC 220V | ||
Power Consumption : 1000W Mainframe weight: 53.6Kg Size(L×W×H):800×500×310 mm | ||
Humidity: 5%-95% Running Temperature: -35 to +80 ℃ |
No | Name | Qty | Unit | Remark |
1 | Antenna | 8 | pcs | Omnidirectional |
2 | Wire controller | 1 | pcs | |
3 | Line controller control line | 1 | pcs | Standard |
4 | Spare Line controller control line | 1 | pcs | 20M |
5 | Power Line | 1 | pcs | Standard |
6 | Hand-pull Box | 1 | pcs | System Accessary |
Input impedence | 50Ω |
standing wave | ≤1.8 |
Gain | 3dBi |
Power Capacity | 150W |
Direction of Polarization | Vertical Polarization |
Cross Modulation | <-107dBm |
Interface Type | 7/16 or N-K |
Lightning Protection | Direct Grounding |
Wind Protectionnn | 60(m/s) |
Pole Diameter | Φ25/40(mm) |
● Prisons, Recording Studios, Banks, Contract Tendering Rooms,
● Churches, Classrooms, Testing Facilities, Security Services,
● Military Units, Secret Services, News Conference Rooms,
● Libraries, Museums, Courts, Border Patrol and Drug Enforcement, Customs, etc.
Step 1 - Open the box
● Open the box. Keep unpacked boxes ready for future removal or shipment.
● check that the open equipment and accessories are in good condition. If any defects or damage are found, please contact your supplier as soon as possible.
Step 2 - Connecting antenna
● Open the suitcase and take out the antenna. Note: do not activate the shield until the antenna and shield are not well connected, otherwise, the shield will be severely damaged. All costs and consequences arising from this will be borne by the user himself.
● Each antenna is connected to the RF output interface of the host computer one-to-one.
Step 3 - Start Jammer
● Connect the host AC~220V port with the power cord in the suitcase: then dial the side red knob switch to the "1" file;
● The start and output power adjustment of the wire controller:
1) Connection wire controller
The 6pin wire control connection line is connected to the 6pin wire control connection
port on the side of the chassis;
2) Control the output and output power of the power amplifier with a wire controller.
[ALL Ch]: screen all 4Channel on / off buttons;
[ALL PA]: power output adjustment keys for all 4Channel of the shield;
[CHX]: the output of Channel X is the Channel number of 1 ~ 8 when the output of
Channel X is turned on / off alone;
[PAX]: regulating the power output of ChannelX alone X is the Channel number of 1 / 8.
The output power regulation is divided into five sections: 20: 20 and 40.
Step 4 - Turn off the Jammer
● the power output switch of each channel is closed;
● Power off:
1) Dial the red knob switch on the side of the chassis to "0";
2) Unplug the power cord;
